| Model Number : | SJ-10030-SK6812RGBW |
| Certification : | CE&ROHS |
| Payment Terms : | T/T, Western Union, PayPal, AliExpress |
| Supply Ability : | 10000m per month |
| Delivery Time : | 3-7 work days |
| Brand Name : | shijilighting |
New Arrival ws2811ic DC5V 30 pixels/m sk6812RGBW Programmable Flexible LED Strips
Features:
1)30 leds per meter led strip SK6812 (ws2811ic)
2)1 integrated RGB LEDs per segment, individually controllable
3)DC5V power requirement
4)10mm wide self-adhesive Tape
5) over 50,000 hours life expectancy
6) non-waterproof& waterproof, IP 20/65/67

Specifications:
| Input Voltage: | 5VDC |
| Max Power Consumption: | 9.5W per mtr |
| LED Quantity: | 30 per mtr |
| LED Classification: | Pixel RGB SMD |
| IC Type | WS2811 |
| Viewing Angle: | 140° |
| Standard Reel Length: | 5mtr |
| Custom Lengths Available: | Yes |
| Dimensions: | 1000mm(L) x 10mm(W) x 7mm(H) |
| Operating Temperature: | -20 ~ +60°C |
| Storage Temperature: | -40~+80 °C |
| IP Rate: | non-waterproof,IP65(silicon tube&epoxy glue) |
| Material: | Super slim flexible PCB |
| PCB Color: | Black and White both avaliable |
| Flexibility: | 360° |
| Brand: | SJ or OEM |
Description:
1.Addressable RGBW Pixel strip, comes with R,G,B,W 4 chips that inserted in only one 5050 diode, more brightness and more colorful than RGB diode;
2. 5V operating voltage, can not over 6v, otherwise,you will destory entire strip;
3. Power/date connectors for easy chaining, and additional power and ground wires for
alternate power connections;
4.Each LED/Pixel can be cut, there is cut linesbetween each LEDs.
5. White PCB/ white diode and black PCB/black diode ar workable.




|
|
