Dmx512 Controllable Led Meteor Light Outdoor Christmas Icicle
Lights
Features:
1. Working with DMX512 protocol directly, stable working
performance and changing smoothly.
2. Built-in regulator circuit, can better to protect the IC and
extend the using time.
3. Wonderful performance operated by Madrix software
4. Double-sided light effects can be seen from 360 degree,
Transparent tube make the light much clear and pure.
5. Environment friendly, no harsh glare and buzzing noise, no
flicker.
6. Parallel DMX signal , avoiding all lights influenced by the
failure of one light in serial connection.
7. Waterproof, energy-saving, low-cost of maintenance, and long
life span.
8. Length: 0.5M, 1M, 1.5M,2M or customized
9. It is very cool for nighclub, KTV,Disco decoration.
Parameters:
| SJ-10032-DMX | SJ-10064-DMX | SJ-10096-DMX | SJ-100128-DMX |
| Products name | 3D DMX LED Vertical Tube Light |
| Hosing Size | D30*L500mm | D30*L1000m | D30*L1500mm | D30*L2000mm |
| Housing material | Transparent PC |
| LED | RGB SMD5050 |
| LED QTY | 32PCS | 64PCS | 96PCS | 128PCS |
| Pixel | 8pixel | 16pixel | 24pixel | 32pixel |
| Beam Angle | 360 degree |
| Input Voltage | DC12V |
| Max Power | 8W | 16W | 24W | 32W |
| Protocol | DMX512 |
| Control Mode | DMX/DVI/ARTNET |
| Adress Setting | Manully |
| Universe | 20 tube one DMX universe | 10tube one DMX universe | 7 tube one DMX universe | 5 tube one DMX universe |
| Protection | IP65/20 | IP65/20 | IP65/20 | IP65/20 |
| Operting Temperature | -20°C--+60°C |
| Storage Temperature | -40°C--+60°C |
| Weight | 0.122kg/pcs | 0.244kg/pcs | 0.345kg/pcs | 0.467kg/pc |
Instruction:
1. Adopt 5050 lamp bead which has high brightness, highly UV
resistance and excellent dampproof performance.
2. Compatible with DMX512 protocol, 16 bit gray, with stable
working performance and changing smoothly.
3. Built-in regulator circuit, can better to protect the IC and
extend the using time.
4. Combine with Germanic MADRIX software.
5. With DMX controller which offered by our company, it can achieve
color fading, skiping, scanning, chasing and play flash and video,
3D effect etc.
6. Double-sided light effects can be seen from 360 degree,
Transparent tube make the light much clear and pure.
7. Environment friendly, no harsh glare and buzzing noise, no
flicker.
8. DMX signal is in parallel connection, avoiding all lights
influenced by the failure of one light in serial connection.
9. After installation, can connect all the lights , DMX address can
be setted up by our coding device disposable.
10. Waterproof, energy-saving, low-cost of maintenance, and long
life span.
11. Length: 0.5M, 1M, 1.5M,2M or customized
Pictures:
Note:
1. Indoor and oudoor using
2. Turn off the power before installment, don't touch the surface
of the lights when light on
3. Please make sure using in the normal environment
4. To avoid using nearby the hot or heat source place,where has the
corrosive gas.
5. Make sure the installment place could afford 10 times of the
weight of light.
6. Installed position must be no shock, no fire hidden danger
7. Do not touch or/and knock the product body during working
Trade Term
1. Payment: T/T , (Western Union is welcomed)
2. Production lead time for 100~500pcs: 5-7days,
500~1000pcs:7-15days
3. Sample can be delivered in 3days
4. By Express(EMS, DHL, UPS etc), By Air or By SeaShipping freight
are quoted under your requests
5. Shipping port: Shenzhen/Guangzhou, Mainland China
6. Logo: According to your requirement
7. Discounts are offered based on order quantities
8. MOQ:5pcs, Welcome sample order
